Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG • Caujolle
  • Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG
  • Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG
  • Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG
  • Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG
  • Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG
How to choose your roulette?

Castor Retractable BLACK WITH A 10 CM STROKE CRANK DIAMETER 200 MM LOAD 750 KG

€397.88 Tax included

REF: 60861

Designed to meet the demands of the most varied industrial environments, this caster with a robust design integrates a crank lift system. It is ideal for moving, positioning, and leveling heavy industrial machines.

  • High load capacity: Unit resistance of 750 kg (up to 2.2 tons for a set of 4 casters).

  • Crank lifting system: Offers a total stroke of 100 mm.

    • Clockwise rotation: raises the machine.

    • Counter-clockwise rotation: lowers the machine.

    • Precision: approximately 2 mm of stroke per crank turn.

  • Adjustable heights:

    • High position: 770 mm

    • Low position: 670 mm

  • Ultra-strong fixation: Side plate of 100 x 150 mm in 6 mm thick steel, equipped with 4 M10 holes.

  • High performance wheel: Made of polyurethane, ensuring excellent durability under static load. It features a double ball bearing to reduce starting friction and facilitate rotation.

Outdoor use: The entire unit is fully painted black to allow for outdoor use. (Note: regular maintenance of the paint is recommended, as the underlying steel is not treated for corrosion resistance).

Easy maintenance: Equipped with a greaser at the wheel to protect the bearings of the crown against wear and corrosion. The internal gears located behind the crank are also accessible for easy re-greasing.

Expédition sous 24h ouvrées

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 200

  • Load capacity in kilograms 750

  • Material of the tread Polyurethane

  • Type of bearing Bearing ball bearing

  • Type fixation Pivoting to plate (plate)

  • Specificities Heavy load

  • Bore in mm 10

  • Dimension plate in mm 100X150

  • Distance between axes in mm 60X110

  • Diameter of fixation in mm M10

  • Wheel width in mm 50

  • Hub length in mm 60

  • Width of the bearing band in mm 50

  • Offset in mm 56

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 15.200 Kg
