Castor EXTRA-LOW FIXING WITH EYE FOR HIGH LOAD BRAKE DIAMETER 50 MM HEIGHT 72 MM LOAD 150 KG - SURB 50 OAF

€52.98 Tax included

REF: 99277

An exceptional model for its robustness and small size.

The principle is simple: this model has a wheel mounted on a 2.5 mm thick steel plate. The wheel has a ball bearing to facilitate movement in all directions.

You can load up to 450 kg on 4 casters while having a maximum total height of 72 mm. This model is therefore very useful for heavy industrial machines on which operators work, as it allows for maintaining a reasonable height.

This model also has a brake to lock the whole unit, ideally installing at least 2 brakes on 4 casters in total. The locking is directional, meaning that when the brake is active, your furniture cannot move forward, and the caster cannot pivot either.

Expédition sous 24h ouvrées

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 50

  • Load capacity in kilograms 150

  • Material of the tread Polyurethane

  • Type of bearing Bearing ball bearing

  • Type fixation A bolt hole (central hole)

  • Height of the roulette in mm 72

  • Specificities Heavy load

  • Bore in mm 6

  • Diameter of fixation in mm M10

  • Wheel width in mm 40

  • Brake With brake

  • Uses Castor industrial

  • Width of the bearing band in mm 40

  • Profile type Dish

  • Offset in mm 25.5

  • Dimensions in mm 85

  • Maximum speed in km/h 1

  • Minimum / Maximum Temperature in °C -20/+80

  • Diameter of the dome 55

  • Weight 0.610 Kg
